| Specifications |
| Output Power |
150W continuous power |
| |
300W surge power |
| Standby Current |
<0.8A (12V) |
| Input Voltage |
DC 10V~15V (12V) |
| Output Voltage |
AC 220V~230V |
| Output Waveform |
Sine Wave |
| Efficiency |
> 85% |
| Output Frequency |
50Hz Or 60Hz |
| Cooling Method |
Fan (Temperaturre Controlled) |
| Battery Low Voltage Alarm |
<10.5V ± 0.5V (12V) |
| Battery Low Voltage Shutdown |
<10V ± 0.5V (12V) |
| Thermal Protection |
65 ± 5°C |
| Protections |
Overload, Output short circuit, Battery voltage high, |
| |
Battery Reverse Polarity (fuse) |
| Fuse |
15A x 1PCS |
| AC Outlet |
1 x AC outlet |
| Dimension (LxWxH) |
225x117x62mm |
| Net Weight |
1.01Kgs |
